TP-Link T2600G Series User Manual

User Guide 524
Configuring Routing IPv4 Static Routing Configuration
2.2 Using the CLI
Follow these steps to create an IPv4 static route.
Step 1 configure
Enter global configuration mode.
Step 2 ip route {
dest-address } { mask } { next-hop-address } [ distance ]
Add an IPv4 static route.
dest-address: Specify the destination IPv4 address of the packets.
mask: Specify the subnet mask of the destination IPv4 address.
next-hop-address: Specify the IPv4 gateway address to which the packet should be sent
next.
distance: Specify the administrative distance, which is a rating of the trustworthiness of the
routing information. A higher value means a lower trust rating. When more than one routing
protocols have routes to the same destination, only the route that has the shortest distance
will be recorded in the IP routing table. The valid values are from 1 to 255 and the default
value is 1.
Step 3 show ip route [ static | connected ]
Verify the IPv4 route entries of the specified type.
Step 4 end
Return to privileged EXEC mode.
Step 5 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to create an IPv4 static route with the destination IP
address as 192.168.2.0, the subnet mask as 255.255.255.0 and the next-hop address as
192.168.0.2:
Switch#configure
Switch(config)#ip route 192.168.2.0 255.255.255.0 192.168.0.2
Switch(config)#show ip route
Codes: C - connected, S - static
* - candidate default
C 192.168.0.0/24 is directly connected, Vlan1
S 192.168.2.0/24 [1/0] via 192.168.0.2, Vlan1
Switch(config)#end
Switch#copy running-config startup-config

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
