Configuring System Logs System Logs Configurations
The following example shows how to configure the local logs on the switch. Save logs of
levels 0 to 5 to the log buffer, and synchronize logs of levels 0 to 2 to the flash every 10
hours:
Switch#configure
Switch(config)#logging buffer
Switch(config)#logging buffer level 5
Switch(config)#logging file flash
Switch(config)#logging file flash frequency periodic 10
Switch(config)#logging file flash level 2
Switch(config)#show logging local-config
Channel Level Status Sync-Periodic
------- ----- ------ -------------
Buffer 5 enable Immediately
Flash 2 enable 10 hour(s)
Console 5 enable Immediately
Monitor 5 enable Immediately
Switch(config)#end
Switch#copy running-config startup-config
2.2.2 Configuring the Remote Logs
You can configure up to four hosts to receive the switch’s system logs. These hosts are
called Log Servers. The switch will forward the log message to the servers once a log
message is generated. To display the logs, the servers should run a log server software
that complies with the syslog standard.
Follow these steps to set the remote log:
Step 1 configure
Enter global configuration mode.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
