TP-Link T2600G Series - Viewing DDM Status

User Guide 142
Configuring DDM (Only for Certain Devices) DDM Configuration
Gi1/0/28 -- -- -- --
Switch(config)#end
2.2.5 Viewing DDM Status
Follow these steps to view the DDM status, which is the digital diagnostic monitoring status
of SFP modules inserted into the switch’s SFP ports.
Step 1 configure
Enter global configuration mode.
Step 2 show ddm status
Displays all the monitoring status of SFP modules.
Step 3 end
Return to Privileged EXEC Mode.
The following example shows how to view SFP ports’ DDM status.
Switch#configure
Switch(config)#show ddm status
Temperature(C) Voltage(V) BiasCurrent(mA) TxPower(mW)
RxPower(mW) DataReady RxLos TxFault
Gi1/0/27 -- -- -- --
-- -- -- --
Gi1/0/28 -- -- -- --
-- -- -- --
Switch(config)#end
