TP-Link T2600G Series User Manual

User Guide 504
Configuring Layer 3 Interfaces Layer 3 Interface Configurations
2
Layer 3 Interface Configurations
To complete IPv4 interface configuration, follow these steps:
1) Create a Layer 3 interface
2) Configure IPv4 parameters of the created interface
3) View detailed information of the created interface
To complete IPv6 interface configuration, follow these steps:
1) Create a Layer 3 interface
2) Configure IPv6 parameters of the created interface
3) View detailed information of the created interface
2.1 Using the GUI
2.1.1 Creating a Layer 3 Interface
Choose the menu L3 FEATURES> Interface to load the following page.
Figure 2-1 Interface Configuration
Follow these steps to create a Layer 3 interface.
1) In the Routing Config section, enable IPv4 routing or IPv6 routing. Then click Apply.
IPv4 Routing Enable IPv4 routing function globally for all Layer 3 interfaces. It is enabled by
default.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
