TP-Link T2600G Series User Manual

Configuring IPv4 IMPB IP-MAC Binding Configuration
User Guide
851
VLAN ID Specify a VLAN ID.
2) In the Scanning Result section, select one or more entries and configure the relevant
parameters. Then click Bind.
Host Name Enter a host name for identification.
IP Address Displays the IP address.
MAC Address Displays the MAC address.
VLAN ID Displays the VLAN ID.
Port Displays the port number.
Protect Type Select the protect type for the entry. The entry will be applied to to the specific
feature. The following options are provided:
None: This entry will not be applied to any feature.
ARP Detection: This entry will be applied to the ARP Detection feature.
IP Source Guard: This entry will be applied to the IP Source Guard feature.
Both This entry will be applied to both of the features.
2.1.3 Binding Entries via DHCP Snooping
With DHCP Snooping enabled, the switch can monitor the IP address obtaining process
of the host, and record the IP address, MAC address, VLAN ID and the connected port
number of the host.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
