User Guide 706
Configuring Access Security Access Security Configurations
2.1.6 Configuring the Serial Port Parameters
Choose the menu SECURITY > Access Security > Serial Port Config to load the following
page.
Figure 2-9 Configuring the Serial Port Parameters
Configure the Baud Rate and click Apply.
Baud Rate Configure the baud rate of the console connection. The default value is 38400 bps.
Data Bits Displays the data bits.
Parity Bits Displays the parity bits.
Stop Bits Displays the stop bits.
2.2 Using the CLI
2.2.1 Configuring the Access Control Feature
Follow these steps to configure the access control:
Step 1 configure
Enter global configuration mode.
