Configuring Private VLAN Private VLAN Configurations
User Guide
281
Gi1/0/2 Promiscuous
Switch(config)#end
Switch#copy running-config startup-config
2.2.3 Configuring the Down-link Port
Follow these steps to add down-link ports to Private VLAN:
Step 1 configure
Enter global configuration mode.
Step 2 interface {fastEthernet
port
| range fastEthernet
port-list
| gigabitEthernet
port
| range
gigabitEthernet
port-list
| ten-gigabitEthernet
port
| range ten-gigabitEthernet
port-list
|
port-channel
port-channel-id
| range port-channel
port-channel-list
}
Enter interface configuration mode.
Step 3 switchport private-vlan host
Configure the port type as host. The port type of down-link port in a secondary VLAN must
be Host. This type of port is used to connect to end users and shield information from
upper-layer devices. The PVID of this port is its secondary VLAN ID.
Step 4 switchport private-vlan host-association
primary-vlan-id secondary-vlan-id vlantype
Add the specified port(s) to the private VLAN.
primary-vlan-id
: Specify the ID of the primary VLAN. The ID ranges from 2 to 4094.
secondary-vlan-id
: Specify the ID of the secondary VLAN. The ID ranges from 2 to 4094.
vlantype
: Specify the secondary VLAN type, either community or isolated.
Step 5 show vlan private-vlan
Verify configurations of private VLAN.
Step 6 show vlan private-vlan interface [fastEthernet
port
| gigabitEthernet
port
| ten-
gigabitEthernet
port
| port-channel
lag-id
]
Verify private VLAN configurations of ports.
port
: Specify the ID of the port to show information.
lag-id
: Specify the ID of the LAG to show information.
Step 7 end
Return to Privileged EXEC Mode.
Step 8 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to configure the port type of port 1/0/3 as Host, and add
it to the private VLAN composed of primary VLAN 6 and secondary VLAN 5.
Switch#configure
