TP-Link T2600G Series User Manual

Configuring ARP ARP Configurations
User Guide
613
■ Viewing ARP Entries
On privileged EXEC mode or any other configuration mode, you can use the following
command to view ARP entries:
show arp [ ip ] [ mac ]
ip: Specify the IP address of your desired ARP entry.
mac: Specify the MAC address of your desired ARP entry.
show ip arp { fastEthernet
port | gigabitEthernet port | ten-gigabitEthernet port | port-channel lagid |
vlan
vid }
Verify the active ARP entries associated with a Layer 3 interface.
port: Specify the number of the routed port.
lagid: Specify the ID of the LAG.
vid: Specify the VLAN interface ID.
2.2.2 Configuring the Gratuitous ARP
■ Configuring Gratuitous ARP Globally
Follow these steps to add static ARP entries:
Step 1 configure
Enter global configuration mode.
Step 2 gratuitous-arp intf-status-up enable
Enable the Layer 3 interface to send a gratuitous ARP packet to detect if its IP address is used
by other devices. It is enabled by default
Step 3 gratuitous-arp dup-ip-detected enable
(Optional) Enable the Layer 3 interface to send a gratuitous packet when the interface received
a gratuitous ARP packet with the same IP address with its own. It is disabled by default.
Step 4 gratuitous-arp learning enable
(Optional) Enable the switch to learn MAC address entries from gratuitous ARP packets.
Generally, the switch only learn MAC address entries form normal ARP packets. With this
option enabled, the switch will also learn MAC address entries from gratuitous ARP packets. By
default, it is disabled.
Step 5 show gratuitous-arp
Show the gratuitous ARP configuration.
Step 6 end
Return to privileged EXEC mode.
Step 7 copy running-config startup-config
Save the settings in the configuration file.
This example shows how to enable Send on IP Interface Status Up, Send on Duplicate IP
Detected and Gratuitous ARP Learning features:

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
