TP-Link T2600G Series User Manual

User Guide 722
Configuring AAA AAA Configuration
■ AAA Application List
The switch supports the following access applications: Console, Telnet, SSH and HTTP.
You can select the configured authentication method lists for each application.
2.1 Using the GUI
2.1.1 Adding Servers
You can add one or more RADIUS/TACACS+ servers on the switch for authentication.
If multiple servers are added, the server that is first added to the group has the highest
priority and authenticates the users trying to access the switch. The others act as backup
servers in case the first one breaks down.
■ Adding RADIUS Server
Choose the menu SECURITY > AAA > RADIUS Config and click
to load the
following page.
Figure 2-1 RADIUS Server Configuration
Follow these steps to add a RADIUS server:
1) Configure the following parameters.
Server IP Enter the IP address of the server running the RADIUS secure protocol.
Shared Key Enter the shared key between the RADIUS server and the switch. The RADIUS
server and the switch use the key string to encrypt passwords and exchange
responses.
Authentication
Port
Specify the UDP destination port on the RADIUS server for authentication
requests. The default setting is 1812.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
