TP-Link T2600G Series User Manual

User Guide 162
Managing MAC Address Table Example for Security Configurations
4
Example for Security Configurations
4.1 Network Requirements
Several departments are connected to the company network as shown in Figure 4-1. Now
the Marketing Department that is in VLAN 10 has network requirements as follows:
■ Free the network system from illegal accesses and MAC address attacks by limiting the
number of access users in this department to 100.
■ Assist the network manager supervising the network with notifications of any new
access users.
Figure 4-1 The Network Topology
Gi1/0/1
Gi1/0/3
Gi1/0/2
R&D Department
VLAN 30
Marketing Department
VLAN 10
Switch
...
Internet
4.2 Configuration Scheme
VLAN Security can be configured to limit the number of access users and in this way to
prevent illegal accesses and MAC address attacks.
MAC Notification and SNMP can be configured to monitor the interface which is used by
the Marketing Department. Enable the new-MAC-learned notification and the SNMP, then
the network manager can get notifications when new users access the network.
Demonstrated with T2600G-28TS, this chapter provides configuration procedures in two
ways: using the GUI and using the CLI.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
