TP-Link T2600G Series User Manual

User Guide 636
Configuring QoS Class of Service Configuration
The following example shows how to configure the trust mode of port 1/0/1 as untrust,
map the port 1/0/1 to 802.1p priority 1 and map 802.1p priority 1 to TC3:
Switch#configure
Switch(config)#interface gigabitEthernet 1/0/1
Switch(config-if)#qos trust mode untrust
Switch(config-if)#qos port-priority 1
Switch(config-if)#exit
Switch(config)#qos cos-map 1 3
Switch(config)#show qos trust interface gigabitEthernet 1/0/1
Port Trust Mode LAG
-------- --------- --------
Gi1/0/1 untrust N/A
Switch(config)#show qos port-priority interface gigabitEthernet 1/0/1
Port CoS Value LAG
-------- --------- --------
Gi1/0/1 CoS 1 N/A
Switch(config)#show qos cos-map
-----+-----+-----+-----+-----+-----+-----+----+----
Tag |0 |1 |2 |3 |4 |5 |6 |7
-----+-----+-----+-----+-----+-----+-----+----+----
TC |TC0 |TC3 |TC2 |TC3 |TC4 |TC5 |TC6 |TC7
-----+-----+-----+-----+-----+-----+-----+----+----
Switch(config)#end
Switch#copy running-config startup-config
2.2.2 Configuring 802.1p Priority
■ Configuring the Trust Mode
Follow these steps to configure the trust mode:
Step 1 configure
Enter global configuration mode

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
