TP-Link T2600G Series User Manual

Configuring Layer 2 Multicast IGMP Snooping Configuration
User Guide
297
2
IGMP Snooping Configuration
To complete IGMP Snooping configuration, follow these steps:
1) Enable IGMP Snooping globally and configure the global parameters.
2) Configure IGMP Snooping for VLANs.
3) Configure IGMP Snooping for ports.
4) (Optional) Configure the advanced IGMP Snooping features:
■ Configure hosts to statically join a group.
■ Configure IGMP accounting and authentication features.
Note:
IGMP Snooping takes effect only when it is enabled globally, in the corresponding VLAN and port at
the same time.
2.1 Using the GUI
2.1.1 Configuring IGMP Snooping Globally
Choose the menu
L2 FEATURES > Multicast > IGMP Snooping > Global Config
to load the
following page.
Figure 2-1 Configure IGMP Snooping Globally
Follow these steps to configure IGMP Snooping globally:
1) In the Global Config section, enable IGMP Snooping globally and configure the global
parameters.
IGMP Snooping Enable or disable IGMP Snooping globally.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
