TP-Link T2600G Series User Manual

Configuring 802.1x 802.1x Configuration
User Guide
763
Step 12 end
Return to privileged EXEC mode.
Step 13 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to enable 802.1x authentication on port 1/0/2, configure
the control type as port-based, and keep other parameters as default:
Switch#configure
Switch(config)#interface gigabitEthernet 1/0/2
Switch(config-if)#dot1x
Switch(config-if)#dot1x port-method port-based
Switch(config-if)#show dot1x interface gigabitEthernet 1/0/2
Port State MAB State GuestVLAN PortControl PortMethod
---- ----- --------- --------- ----------- ----------
Gi1/0/2 disabled disabled 0 auto port-based
MaxReq QuietPeriod SuppTimeout Authorized LAG
------ ----------- ----------- ---------- ---
3 10 30 unauthorized N/A
Switch(config-if)#end
Switch#copy running-config startup-config
2.2.4 Viewing Authenticator State
You can view the authenticator state. If needed, you can also initialize or reauthenticate the
specific client:
Step 1 show dot1x auth-state interface [fastEthernet port | gigabitEthernet port |
tengigabitEthernet
port ]
Displays the authenticator state.
Step 2 configure
Enter global configuration mode.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
