TP-Link T2600G Series User Manual

User Guide 858
Configuring IPv4 IMPB ARP Detection Configuration
3
ARP Detection Configuration
To complete ARP Detection configuration, follow these steps:
1) Add IP-MAC Binding entries.
2) Enable ARP Detection.
3) Configure ARP Detection on ports.
4) View ARP statistics.
3.1 Using the GUI
3.1.1 Adding IP-MAC Binding Entries
In ARP Detection, the switch detects the ARP packets based on the binding entries in the
IP-MAC Binding Table. So before configuring ARP Detection, you need to complete IP-MAC
Binding configuration. For details, refer to IP-MAC Binding Configuration.
3.1.2 Enabling ARP Detection
Choose the menu SECURITY > IPv4 IMPB > ARP Detection > Global Config to load the
following page.
Figure 3-1 ARP Detection Global Config
Follow these steps to enable ARP Detection:
1) In the Global Config section, enable ARP Detection and configure the related
parameters. Click Apply.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
