TP-Link T2600G Series User Manual

User Guide 448
Configuring LLDP LLDP Configurations
2.1.2 Configuring LLDP For the Port
Choose th menu L2 FEATURES > LLDP > LLDP Config > Port Config to load the following
page.
Figure 2-2 Port Config
Follow these steps to configure the LLDP feature for the interface.
1) Select one or more ports to configure.
2) Configure the Admin Status and Notification Mode for the port.
Admin Status Set Admin Status for the port to deal with LLDP packets.
Tx&Rx: The port transmits LLDP packets and receives LLDP packets.
Rx_Only: The port only receives LLDP packets.
Tx_Only: The port only transmits LLDP packets.
Disable: The port will not transmit LLDP packets or drop the received LLDP
packets.
Notification
Mode
(Optional) Enable the switch to send trap messages to the NMS when the
information of the neighbor device connected to this port changes.
Management
Address
Specify the Management IP address of the port to be notified to the neighbor.
Value 0.0.0.0 means the port will notify its default management address to the
neighbor.
3) Select the TLVs (Type/Length/Value) included in the LLDP packets according to your
needs.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
