TP-Link T2600G Series User Manual

Configuring Protocol VLAN Protocol VLAN Configuration
User Guide
205
802.1p Priority Specify the 802.1p priority for the packets that belong to the protocol VLAN. The
switch will determine the forwarding sequence according this value. The packets
with larger value of 802.1p priority have the higher priority.
2) Select the desired ports. Click Create.
Note:
The member port of an LAG (Link Aggregation Group) follows the configuration of the LAG and not its
own. The configurations of the port can take effect only after it leaves the LAG.
2.2 Using the CLI
2.2.1 Configuring 802.1Q VLAN
Before configuring protocol VLAN, create an 802.1Q VLAN and set the port type according
to network requirements. For details, refer to Configuring 802.1Q VLAN.
2.2.2 Creating a Protocol Template
Follow these steps to create a protocol template:
Step 1 configure
Enter global configuration mode.
Step 2 protocol-vlan template name
protocol-name frame { ether_2 ether-type type | snap
ether-type
type | llc dsap dsap_type ssap ssap_type }
Create a protocol template.
protocol-name: Specify the protocol name with 1 to 8 characters.
type : Enter4 hexadecimal numbers as the Ethernet protocol type for the protocol template.
It is the Ether Type field in the frame and is used to identify the data type of the frame.
dsap_type : Enter 2 hexadecimal numbers as the DSAP value for the protocol template. It is
the DSAP field in the frame and is used to identify the data type of the frame.
ssap_type : Enter 2 hexadecimal numbers as the SSAP value for the protocol template. It is
the SSAP field in the frame and is used to identify the data type of the frame.
Step 3 show protocol-vlan template
Verify the protocol templates.
Step 4 end
Return to Privileged EXEC Mode.
Step 5 copy running-config startup-config
Save the settings in the configuration file.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
