User Guide 464
Configuring LLDP Viewing LLDP Settings
4.1.2 Viewing LLDP Statistics
Choose the menu L2 FEATURES > LLDP > LLDP Config > Statistics Info to load the
following page.
Figure 4-3 Static Info
Follow these steps to view LLDP statistics:
1) In the Auto Refresh section, enable the Auto Refresh feature and set the Refresh Rate
according to your needs. Click Apply.
2) In the Global Statistics section, view the global statistics of the local device.
Last Update Displays the time when the statistics updated.
Total Inserts Displays the total number of neighbors during latest update time.
Total Deletes Displays the number of neighbors deleted by the local device. The port will delet
neighbors when the port is disabled or the TTL of the LLDP packets sent by the
neighbor is 0.
Total Drops Displays the number of neighbors dropped by the local device. Each port can
learn a maximum of 80 neighbor device, and the subsquent neighbors will be
dropped when the limit is exceeded.
