TP-Link T2600G Series User Manual

Monitoring Traffic Traffic Monitor
User Guide
951
1.2 Using the CLI
On privileged EXEC mode or any other configuration mode, you can use the following
command to view the traffic information of each port or LAG:
show interface counters [ fastEthernet port | gigabitEthernet port | ten-gigabitEthernet port | port-
channel
port-channel-id ]
port : The port number.
port-channel-id : The group number of the LAG.
If you enter no port number or group number, the information of all ports and LAGs will be displayed.
The displaying information includes:
Tx Collisions: Displays the number of collisions experienced by a port during packet transmissions.
Tx Ucast / Tx Mcast / Tx Bcast / Tx Jumbo: Displays the number of valid unicast / multicast / broadcast /
jumbo packets transmitted on the port. Error frames are not counted.
Tx Pkts: Displays the number of packets transmitted on the port. Error packets are not counted.
Tx Bytes: Displays the number of bytes transmitted on the port. Error packets are not counted.
Rx Ucast / Rx Mcast / Rx Bcast / Rx Jumbo: Displays the number of valid unicast / multicast / broadcast /
jumbo packets received on the port. Error frames are not counted.
Rx Alignment: Displays the number of the received packets that have a Frame Check Sequence (FCS) with
a non-integral octet (Alignment Error). The size of the packet is between 64 bytes and 1518 bytes.
Rx UnderSize: Displays the number of the received packets (excluding error packets) that are less than 64
bytes long.
Rx 64Pkts: Displays the number of the received packets (including error packets) that are 64 bytes long.
Rx 65-127Pkts: Displays the number of the received packets (including error packets) that are between 65
and 127 bytes long.
Rx 128-255Pkts: Displays the number of the received packets (including error packets) that are between
128 and 255 bytes long.
Rx 256-511Pkts: Displays the number of the received packets (including error packets) that are between
256 and 511 bytes long.
Rx 512-1023Pkts: Displays the number of the received packets (including error packets) that are between
512 and 1023 bytes long.
Rx 1024-1518Pkts: Displays the number of the received packets (including error packets) that are between
1024 and 1518 bytes long.
Rx Pkts: Displays the number of packets received on the port. Error packets are not counted.
Rx Bytes: Displays the number of bytes received on the port. Error packets are not counted.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
