TP-Link T2600G Series User Manual

User Guide 506
Configuring Layer 3 Interfaces Layer 3 Interface Configurations
2.1.2 Configuring IPv4 Parameters of the Interface
In Figure 2-1 you can view the corresponding interface you have created in the Interface
Config section. On the corresponding interface entry, click Edit IPv4 to load the following
page and edit the IPv4 parameters of the interface.
Figure 2-3 Configuring the IPv4 Parameters
1) In the Modify IPv4 Interface section, configure relevant parameters for the interface
according to your actual needs. Then click Apply.
Interface ID Displays the interface ID.
Admin Status Enable the Layer 3 capabilities for the interface.
Interface Name (Optional) Enter a name for the interface.
IP Address Mode Specify the IP address assignment mode of the interface.
None: No IP address will be assigned.
Static: Assign an IP address manually.
DHCP: Obtain an IP address through DHCP.
BOOTP: Obtain an IP address through BOOTP.
IP Address Specify the IP address of the interface if you choose “Static” as the IP address
assignment mode.
Subnet Mask Specify the subnet mask of the interface’s IP address.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
