User Guide 190
Configuring MAC VLAN Configuration Example
egress rule as Untagged; for the ports connecting to other switches, set the egress rule
as Tagged.
2) On Switch 1 and Switch 2, bind the MAC addresses of the laptops to their
corresponding VLANs, and enable MAC VLAN for the ports.
Demonstrated with T2600G-28TS, the following sections provide configuration procedure
in two ways: using the GUI and using the CLI.
3.3 Using the GUI
■ Configurations for Switch 1 and Switch 2
The configurations of Switch 1 and Switch 2 are similar. The following introductions take
Switch 1 as an example.
1) Choose the menu L2 FEATURES > VLAN > 802.1Q VLAN > VLAN Config and click
to load the following page. Create VLAN 10, and add untagged port 1/0/1 and
tagged port 1/0/2 to VLAN 10. Click Create.
