TP-Link T2600G Series User Manual

User Guide 596
Configuring DHCP Service Configuration Examples
2) Configuring the DHCP Server
The detailed configurations on the DHCP server may be different among different
devices. You can refer to the related document that is for the DHCP server you use.
Demonstrated with a Linux ISC DHCP Server, 5.5.4 Configuring the DHCP Server
provides information about how to set its DHCP configuration file.
5.5.3 Configuring the DHCP Relay Switch
Using the GUI
1) Choose the menu L3 FEATURES > DHCP Service > DHCP L2 Relay > Global Config to
load the following page. In the Global Config section, enable DHCP L2 Relay globally
and click Apply. Enable DHCP L2 Relay on VLAN 1 and click Apply.
Figure 5-33 Enabling DHCP L2 Relay
2) Choose the menu L3 FEATURES > DHCP Service > DHCP L2 Relay > Port Config
to load the following page. Select port 1/0/1, enable Option82 Support and select
Option82 Policy as Replace. You can configure other parameters according to your
needs. In this example, keep Format as Normal and Remote ID Customization as
Disabled. Enable Circuit ID Customization and specify the Circuit ID as Group1. Click
Apply.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
