TP-Link T2600G Series User Manual

Managing System Time Range Configuration
User Guide
73
8
Time Range Configuration
To complete Time Range configuration, follow these steps:
1) Add time range entries.
2) Configure Holiday time range.
8.1 Using the GUI
8.1.1 Adding Time Range Entries
Choose the menu SYSTEM > Time Range > Time Range Config and click to load
the following page.
Figure 8-1 Configuring Time Range
Follow these steps to add time range entries:
1) In the Time-Range Config section, specify a name for the entry and select the Holiday
mode.
Name Specify a name for the entry.
Holiday Select to include or exclude the holiday in the time range.
Exclude: The time range will not take effect on holiday.
Include: The time range will not be affected by holiday.
To configure Holiday, refer to Configuring Holiday.
2) In the Period Time Config section, click and the following window will pop up.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
