TP-Link T2600G Series User Manual

Configuring Layer 2 Multicast MVR Configuration
User Guide
335
Follow these steps to statically add ports to an MVR group:
1) Select the ports to add them to the MVR group.
2) Click Save.
4.2 Using the CLI
4.2.1 Configuring 802.1Q VLANs
Before configuring MVR, create an 802.1Q VLAN as the multicast VLAN. Add the all source
ports to the multicast VLAN as tagged ports. Configure 802.1Q VLANs for the receiver
ports according to network requirements. Note that receiver ports can only belong to one
VLAN and cannot be added to the multicast VLAN. For details, refer to Configuring 802.1Q
VLAN.
4.2.2 Configuring MVR Globally
Follow these steps to configure MVR globally:
Step 1 configure
Enter global configuration mode.
Step 2 mvr
Enable MVR Globally.
Step 3 mvr mode { compatible | dynamic }
Configure the MVR mode as compatible or dynamic.
compatible: In this mode, the switch does not forward report or leave messages from the
hosts to the IGMP querier. So the IGMP querier cannot learn the multicast groups membership
information from the switch. You have to statically configure the IGMP querier to transmit all
the required multicast streams to the switch via the multicast VLAN.
dynamic: In this mode, after receiving report or leave messages from the hosts, the switch
will forward them to the IGMP querier via the multicast VLAN (with appropriate translation of
the VLAN ID). So the IGMP querier can learn the multicast groups membership information
through the report and leave messages, and transmit the multicast streams to the switch via
the multicast VLAN according to the multicast forwarding table.
Step 4 mvr vlan
vlan-id
Specify the multicast VLAN.
vlan-id: Specify the ID of the multicast VLAN. Valid values are from 1 to 4094.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
