TP-Link T2600G Series User Manual

User Guide 498
Configuring PPPoE ID Insertion PPPoE ID Insertion Configuration
Circuit-ID Enable or disable the Circuit-ID Insertion feature. With this option enabled,
the switch will insert a Circuit ID to the received PPPoE Discovery packet
on this port.
Circuit-ID Type Select the type of the Circuit ID. The following options are provided:
IP: The circuit ID includes the following three parts: the source MAC
address of the received packet, the IP address of the switch and the port
number. This is the default value.
MAC: The circuit ID includes the following three parts: the source MAC
address of the packet, the MAC address of the switch and the port
number.
UDF: The circuit ID includes the following three parts: the source MAC
address of the packet, the user-specified string and the port number.
UDF Only: Only the user specified string will be used to encode the
Circuit-ID option.
UDF Value If UDF or UDF Only is selected, specify a string with at most 40 characters
to encode the Circuit-ID option.
Remote-ID Enable or disable the Remote-ID Insertion feature. With this option
enabled, the switch will insert a Remote ID to the received PPPoE
Discovery packet on this port.
Remote-ID Value Specify a string with at most 40 characters to encode the Remote-iID
option.
Note:
The member port of an LAG (Link Aggregation Group) follows the configuration of the LAG and not its
own. The configurations of the port can take effect only after it leaves the LAG.
2.2 Using the CLI
Follow these steps to configure PPPoE ID Insertion:
Step 1 configure
Enter global configuration mode.
Step 2 pppoe id-insertion
Globally enable the PPPoE ID Insertion feature.
Step 3 interface { fastEthernet
port | range fastEthernet port-list | gigabitEthernet port | range
gigabitEthernet
port-list | ten-gigabitEthernet port | range ten-gigabitEthernet port-list }
Enter interface configuration mode.
Step 4 pppoe circuit-id
Enable Circuit-ID Insertion feature, and the switch will insert a Circuit ID to the received
PPPoE Discovery packet on this port.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
