TP-Link T2600G Series User Manual

Configuring GVRP GVRP Configuration
User Guide
259
2.1 Using the GUI
Choose the menu L2 FEATURES > VLAN > GVRP > GVRP Config to load the following
page.
Figure 2-1 GVRP Config
Follow these steps to configure GVRP:
1) In the GVRP section, enable GVRP globally, then click Apply.
2) In the Port Config section, select one or more ports, set the status as Enable and
configure the related parameters according to your needs.
Port Select the desired port for GVRP configuration. It is multi-optional.
Status Enable or disable GVRP on the port. By default, it is disabled.
Registration
Mode
Select the GVRP registration mode for the port.
Normal: In this mode, the port can dynamically register and deregister VLANs,
and transmit both dynamic and static VLAN registration information.
Fixed: In this mode, the port is unable to dynamically register and deregister
VLANs, and can transmit only the static VLAN registration information.
Forbidden: In this mode, the port is unable to dynamically register and deregister
VLANs, and can transmit only the information of VLAN 1.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
