TP-Link T2600G Series User Manual

User Guide 754
Configuring 802.1x 802.1x Configuration
VLAN
Assignment
Enable or disable the 802.1x VLAN assignment feature. 802.1x VLAN assignment is
a technology allowing the RADIUS server to send the VLAN assignment to the port
when the port is authenticated.
If the assigned VLAN does not exist on the switch, the switch will create the related
VLAN automatically, add the authenticated port to the VLAN and change the PVID
based on the assigned VLAN.
If the assigned VLAN exists on the switch, the switch will directly add the
authenticated port to the related VLAN and change the PVID instead of creating a
new VLAN.
If no VLAN is supplied by the RADIUS server or if 802.1x authentication is disabled,
the port will be in its original VLAN after successful authentication.
2) Click Apply.
2.1.3 Configuring 802.1x on Ports
Choose the menu SECURITY > 802.1x > Port Config to load the following page.
Figure 2-7 Port Config
Follow these steps to configure 802.1x authentication on the desired port:
1) Select one or more ports and configure the following parameters:
Status Enable 802.1x authentication on the port.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
