TP-Link T2600G Series User Manual

User Guide 340
Configuring Layer 2 Multicast Multicast Filtering Configuration
5
Multicast Filtering Configuration
To complete multicast filtering configuration, follow these steps:
1) Create the IGMP profile or MLD profile.
2) Configure multicast groups a port can join and the overflow action.
5.1 Using the GUI
5.1.1 Creating the Multicast Profile
You can create multicast profiles for both IPv4 and IPv6 network. With multicast profile,
the switch can define a blacklist or whitelist of multicast groups so as to filter multicast
sources.
The process for creating multicast profiles for IPv4 and IPv6 are similar. The following
introductions take creating an IPv4 profile as an example.
Choose the menu L2 FEATURES > Multicast > Multicast Filtering > IPv4 Profile, and click
to load the following page.
Note:
To create a multicast profile for IPv6, choose the menu L2 FEATURES > Multicast > Multicast
Filtering > IPv6 Profile.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
