Configuring Layer 2 Multicast Multicast Filtering Configuration
User Guide
341
Figure 5-1 Create IPv4 Profile
Follow these steps to create a profile.
1) In the General Config section, specify the Profile ID and Mode.
Profile ID Enter a profile ID between 1 and 999.
Mode Select Permit or Deny as the filtering mode.
Permit: Acts as a whitelist and only allows specific member ports to join specified
multicast groups.
Deny: Acts as a blacklist and prevents specific member ports from joining specific
multicast groups.
2) In the IP-Range section, click
to load the following page. Configure the start IP
address and end IP address of the multicast groups to be filtered, and click Create.
