Configuring Layer 2 Multicast IGMP Snooping Configuration
User Guide
303
Choose the menu
L2 FEATURES > Multicast > IGMP Snooping > Static Group Config
and
click
to load the following page.
Figure 2-4 Configure Hosts to Statically Join a Group
Follow these steps to configure hosts to statically join a group:
1) Specify the multicast IP address, VLAN ID. Select the ports to be the static member
ports of the multicast group.
Multicast IP Specify the address of the multicast group that the hosts need to join.
VLAN ID Specify the VLAN that the hosts are in.
Member Ports Select the ports that the hosts are connected to. These ports will become the
static member ports of the multicast group and will never age.
2) Click Create.
2.1.5 Configuring IGMP Accounting and Authentication Features
You can enable IGMP accounting and authentication according to your need. IGMP
accounting is configured globally, and IGMP authentication can be enabled on a per-port
basis.
To use these features, you should also set up a RADIUS server and go to SECURITY > AAA
> RADIUS Config to configure RADIUS server for the switch.
