TP-Link T2600G Series User Manual

Configuring Port Security Port Security Configuration
User Guide
775
Learn Address
Mode
Select the learn mode of the MAC addresses on the port. Three modes are
provided:
Delete on Timeout: The switch will delete the MAC addresses that are not used
or updated within the aging time. It is the default setting.
Delete on Reboot: The learned MAC addresses are out of the influence of the
aging time and can only be deleted manually. The learned entries will be cleared
after the switch is rebooted.
Permanent: The learned MAC addresses are out of the influence of the aging
time and can only be deleted manually. The learned entries will be saved even the
switch is rebooted.
Status Select the status of Port Security. Three kinds of status can be selected:
Drop: When the number of learned MAC addresses reaches the limit, the port
will stop learning and discard the packets with the MAC addresses that have not
been learned.
Forward: When the number of learned MAC addresses reaches the limit, the port
will stop learning but send the packets with the MAC addresses that have not
been learned.
Disable: The number limit on the port is not effective, and the switch follows the
original forwarding rules. It is the default setting.
2) Click Apply.
Note:
•
Port Security cannot be enabled on the member ports of a LAG, and the port with Port Security
enabled cannot be added to a LAG.
•
On one port, Port Security and 802.1x cannot be enabled at the same time.
2.2 Using the CLI
Follow these steps to configure Port Security:
Step 1 configure
Enter global configuration mode.
Step 2 interface { fastEthernet
port | range fastEthernet port-list | gigabitEthernet port | range
gigabitEthernet port-list | ten-gigabitEthernet port | range ten-gigabitEthernet port-list }
Enter interface configuration mode.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
