Configuring QoS Bandwidth Control Configuration
Step 3 bandwidth {ingress ingress-rate | egress egress-rate }
Configure the upper rate limit for the port to receive and send packets.
ingress-rate: Configure the upper rate limit for receiving packets on the port. The valid values
are from 0 to 1000000 Kbps.
egress-rate: Configure the upper rate limit for sending packets on the port. The valid values
are from 0 to 1000000 Kbps.
Step 4 show bandwidth interface [fastEthernet
port | gigabitEthernet port | ten-gigabitEthernet
port | port-channel port-channel-id ]
Verify the ingress/egress rate limit for forwarding packets on the port or LAG. If no port or LAG
is specified, it displays the upper ingress/egress rate limit for all ports or LAGs.
Step 5 end
Return to privileged EXEC mode.
Step 6 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to configure the ingress-rate as 5120 Kbps and egress-
rate as 1024 Kbps for port 1/0/5:
Switch#configure
Switch(config)#interface gigabitEthernet 1/0/5
Switch(config-if)#bandwidth ingress 5120 egress 1024
Switch(config-if)#show bandwidth interface gigabitEthernet 1/0/5
Port IngressRate(Kbps) EgressRate(Kbps) LAG
--------- ---------------------- ---------------------- ------------
Gi1/0/5 5120 1024 N/A
Switch(config-if)#end
Switch#copy running-config startup-config
3.2.2 Configuring Storm Control
Follow these steps to configure the upper rate limit on the port for forwarding broadcast
packets, multicast packets and unknown unicast frames:
Step 1 configure
Enter global configuration mode

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
