TP-Link T2600G Series User Manual

Configuring sFlow (Only for Certain Devices) Overview
User Guide
963
1
Overview
Note:
T2600G-18TS does not support sFlow.
sFlow (Sampled Flow) is a technology for monitoring high-speed switched and routed
networks. It provide complete visibility into network activity. With sFlow, you can analyze
traffic statistics and monitor the network usage, thus implement effective management
and control of network resources.
The sFlow monitoring system consists of an sFlow Agent and an sFlow Collector.
sFlow Agent
The sFlow Agent is embedded in a switch or router or in a standalone probe. It uses
sampling technology to capture traffic statistics from the device it is monitoring,
and packages the sampled data into sFlow datagrams. sFlow datagrams are used to
immediately forward the sampled data to an sFlow Collector for analysis.
The switch provides a packet-based sFlow, which samples one packet out of a specified
number of packets.
sFlow Collector
The sFlow Collector is installed in a host. It analyzes sFlow datagrams to produce a rich,
real-time, network-wide view of traffic flows.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
