Notification Configurations
The following example shows how to configure an NMS host with the parameters shown in
Table 3-1.
Table 3-1 Parameters for the NMS Hosts
Parameter Value
IP Address 172.16.1.222
UDP Port 162
User Name admin
Security Model v3
Security Level authPriv
Notification Type Inform
Retry Times 3
Timeout Interval 100 seconds
Switch#configure
Switch(config)#snmp-server host 172.16.1.222 162 admin smode v3 slev authPriv type
inform retries 3 timeout 100
Switch(config)#show snmp-server host
No. Des-IP UDP Name SecMode SecLev Type Retry Timeout
--- ------ ----- ---- ------- ------ ---- ----- -------
1 172.16.1.222 162 admin v3 authPriv inform 3 100
Switch(config)#end
Switch#copy running-config startup-config
3.2.2 Enabling SNMP Traps
The switch supports many types of SNMP traps, like SNMP standard traps, ACL traps,
and VLAN traps, and the corresponding commands are different. With a trap enabled, the
switch will send the corresponding trap message to the NMS when the trap is triggered.
Follow these steps to enable the traps according to your needs.
■ Enabling the SNMP Standard Traps Globally
Step 1 configure
Enter Global Configuration Mode.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
