Configuring OAM Ethernet OAM Configurations
Mode Select OAM mode for the port.
Active: The port in this mode can initiate OAM connection. It is the default setting.
Passive: The port in this mode cannot initiate OAM connection or send loopback
control OAMPDUs.
Note: OAM connection cannot be established between two ports in passive mode.
Make sure that at least one side is in active mode.
Status Enable or disable OAM on the port. By default, it is disabled.
2) Click Apply.
2.1.2 Configuring Link Monitoring
Choose the menu MAINTENANCE > Ethernet OAM > Link Monitoring > Link Monitoring
to load the following page.
Figure 2-2 Configure Link Monitoring
Follow these steps to configure Link Monitoring:
1) In the Link Event section, select a Link Event type to configure.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
