TP-Link T2600G Series User Manual

User Guide 1028
SNMP Configurations
Figure 2-3 Creating an SNMP View
View Name Set the view name with 1 to 16 characters. A complete view consists of all MIB
objects that have the same view name.
View Type Set the view to include or exclude the related MIB object.
Include: The NMS can view or manage the function indicated by the object.
Exclude: The NMS cannot view or manage the function indicated by the object.
MIB Object ID Enter a MIB Object ID to specify a specific function of the device. When a MIB Object
ID is specified, all its child Object IDs are specified. For specific ID rules, refer to the
device related MIBs.
2) Click Create.
2.1.3 Creating SNMP Communities (For SNMP v1/v2c)
Choose the menu MAINTENANCE > SNMP > SNMP v1/v2c and click to load the
following page.
Figure 2-4 Creating an SNMP Community
Follow these steps to create an SNMP community:
1) Set the community name, access rights and the related view.
Community Name Configure the community name. This community name is used like a password
and the NMS can access the specified MIB objects of the switch using the same
community name.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
