TP-Link T2600G Series User Manual

User Guide 610
Configuring ARP ARP Configurations
Figure 2-4 Configuring Proxy ARP
Select the desired interface and enable proxy ARP. Then click Apply.
IP Address Displays the IP address of the Layer 3 interface
Subnet Mask Displays the subnet mask of the IP address.
Status Enable proxy ARP feature on the interface. The interface will respond the ARP request
sender with its own MAC address.
2.1.5 Configuring Local Proxy ARP
Local Proxy ARP is used in the situation that two devices are in the same VLAN but isolated
on the layer 2 ports.
Choose the menu L3 FEATURES > ARP > Proxy ARP > Local Proxy ARP to load the
following page.
Figure 2-5 Configuring Local Proxy ARP
Select the desired interface and enable local proxy ARP. Then click Apply.
IP Address Displays the IP address of the Layer 3 interface
Subnet Mask Displays the subnet mask of the IP address.
Status Enable local proxy ARP feature on the interface. The interface will respond the ARP
request sender with its own MAC address.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
