TP-Link T2600G Series User Manual

Configuring QoS Bandwidth Control Configuration
User Guide
647
3
Bandwidth Control Configuration
With bandwidth control configurations, you can:
■ Configure rate limit
■ Configure storm control
3.1 Using the GUI
3.1.1 Configuring Rate Limit
Choose the menu QoS > Bandwidth Control > Rate Limit to load the following page.
Figure 3-1 Configuring Rate Limit
Follow these steps to configure the Rate Limit function:
1) Select the desired port and configure the upper rate limit to receive and send packets.
Ingress Rate (0-
1,000,000Kbps)
Configure the upper rate limit for receiving packets on the port. The valid values
are from 0 to 1000000 Kbps and 0 means the ingress rate limit is disabled.
Egress Rate (0-
1,000,000Kbps)
Configure the bandwidth for sending packets on the port. The valid values are
from 0 to 1000000 Kbps and 0 means the egress rate limit is disabled.
2) Click Apply.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
