TP-Link T2600G Series User Manual

User Guide 646
Configuring QoS Class of Service Configuration
Step 5 show qos queue interface [fastEthernet port | gigabitEthernet port | ten-gigabitEthernet
port | port-channel port-channel-id ]
Verify the scheduler settings..
Step 6 end
Return to privileged EXEC mode.
Step 7 copy running-config startup-config
Save the settings in the configuration file.
Note:
With ACL Redirect feature, the switch maps all the packets that meet the configured ACL rules to the
new TC queue, regardless of the mapping relations configured in this section.
The following example shows how to specify the scheduler settings for port 1/0/1. Set the
scheduler mode of TC1 as sp mode, set the scheduler mode of TC4 as wrr mode and set
the queue weight as 5. Set the minimum bandwidth of TC4 as 10.
Switch#configure
Switch(config)#interface gigabitEthernet 1/0/1
Switch(config-if)#qos queue 1 mode sp
Switch(config-if)#qos queue 4 mode wrr weight 5
Switch(config-if)#qos queue 4 bandwidth 10
Switch(config-if)#show qos queue interface gigabitEthernet 1/0/1
Gi1/0/1----LAG: N/A
Queue Schedule Mode Weight Min Bandwidth(%)
----- ---------- ----- ----------
TC0 WRR 1 0%
TC1 Strict N/A 0%
TC2 WRR 1 0%
TC3 WRR 1 0%
TC4 WRR 5 10%
TC5 WRR 1 0%
TC6 WRR 1 0%
TC7 WRR 1 0%
Switch(config-if)#end
Switch#copy running-config startup-config

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
