TP-Link T2600G Series User Manual

Configuring OAM Ethernet OAM Configurations
User Guide
983
2.1.4 Configuring Remote Loopback
Choose the menu MAINTENANCE > Ethernet OAM > Remote Loopbak to load the
following page.
Figure 2-4 Configure Remote Loopback
Follow these steps to configure Remote Loopback:
1) Select one or more ports and configure the relevant options.
Received Remote
Loopback
Choose to ignore or to process the received remote loopback requests.
Remote
Loopback
Start or stop the remote loopback process. The port to be configured should be
in active mode and has established OAM connection with the peer.
Start: Request the remote peer to start the OAM remote loopback mode.
Stop: Request the remote peer to stop the OAM remote loopback mode.
2) Click Apply.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
