TP-Link T2600G Series User Manual

Configuring Spanning Tree STP/RSTP Configurations
User Guide
397
Designated Bridge Displays the bridge ID of the designated bridge. The designated bridge is the
switch that has designated ports.
Root Port Displays the root port of the current switch.
Latest TC Time Displays the latest time when the topology is changed.
TC Count Displays how many times the topology has changed.
2.2 Using the CLI
2.2.1 Configuring STP/RSTP Parameters on Ports
Follow these steps to configure STP/RSTP parameters on ports:
Step 1 configure
Enter global configuration mode.
Step 2 interface {fastEthernet
port | range fastEthernet port-list | gigabitEthernet port | range
gigabitEthernet
port-list | ten-gigabitEthernet port | range ten-gigabitEthernet port-list |
port-channel
port-channel-id | range port-channel port-channel-list }
Enter interface configuration mode.
Step 3 spanning-tree
Enable spanning tree function for desired ports.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
