TP-Link T2600G Series User Manual

User Guide 396
Configuring Spanning Tree STP/RSTP Configurations
Figure 2-3 Verifying the STP/RSTP Configurations
The STP Summary section shows the summary information of spanning tree :
Spanning Tree Displays the status of the spanning tree function.
Spanning Tree Mode Displays the spanning tree mode.
Local Bridge Displays the bridge ID of the local bridge. The local bridge is the current switch.
Root Bridge Displays the bridge ID of the root bridge.
External Path Cost Displays the root path cost from the switch to the root bridge.
Regional Root Bridge It is the root bridge of IST. It is not displayed when you choose the spanning tree
mode as STP/RSTP.
Internal Path Cost The internal path cost is the root path cost from the switch to the root bridge of
IST. It is not displayed when you choose the spanning tree mode as STP/RSTP.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
