TP-Link T2600G Series User Manual

Configuring DHCP Service Configuration Examples
User Guide
593
DHCP relay state: enabled
...
DHCP relay helper address is configured on the following interfaces:
Interface Helper address
------------ -------------------
VLAN2 192.168.0.59
...
View port settings:
Switch#show ip dhcp relay information interface
Interface Option82 Status Operation Strategy Format Circuit ID ...
--------- ---------------- ------------------ ------- --------- ...
Gi1/0/1 Enable Replace Normal Default:VLAN-PORT ...
Gi1/0/2 Enable Replace Normal Default:VLAN-PORT ...
...
5.4.4 Configuring the DHCP Server
Note:
•
Make sure the DHCP server supports Option82 and more than one DHCP address pool.
•
To make sure the DHCP server can reach the computers, you can create static routes or enable
dynamic routing protocol like RIP on the DHCP server.
•
In this section, we use different notations to distinguish ASCII strings from hexadecimal
numbers. An ASCII string is enclosed with quotation marks, such as “123”, while a hexadecimal
number is divided by colon into parts of two digits, such as 31:32:33.
On the DHCP server, you need to create two DHCP classes to identify the Option 82
payloads of DHCP request packets from Group 1 and Group 2, respectively.
In this example, the DHCP relay agent uses the default circuit ID and remote ID in TLV
format. According to packet formats described in Table 1-1 and Table 1-2, the sub-options
of the two groups are as shown in the following table.
Table 5-1 Sub-options of Group1 and Group 2
Group Sub-option Type (Hex) Length (Hex) Value (Hex)
1
Circuit ID 00 04 00:02:00:01
Remote ID 00 06 00:00:FF:FF:27:12

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
