TP-Link T2600G Series User Manual

User Guide 234
Configuring VLAN-VPN Configuration Examples
1) Configure 802.1Q VLAN on switch 1. The parameters are shown below:
VLAN 100 VLAN 200 VLAN 1050 PVID
Port 1/0/1 - - Tagged Keep the
default value
Port 1/0/2 Tagged Tagged Untagged 1050
2) Configure 802.1Q VLAN on switch 3. The parameters are shown below:
VLAN 100 VLAN 200 PVID
Port 1/0/1 Untagged - 100
Port 1/0/2 - Untagged 200
Port 1/0/3 Tagged Tagged Keep the
default value
3) Configure VLAN VPN on switch 1. Set port 1/0/1 as NNI port and port 1/0/2 as UNI port;
configure the TPID as 0x9100.
Demonstrated with T2600G-28TS, this chapter provides configuration procedures in two
ways: using the GUI and using the CLI.
4.1.3 Using the GUI
■ Configuring Switch 1:
1) Go to L2 FEATURES > VLAN > 802.1Q VLAN to create VLAN 100, VLAN 200 and VLAN
1050. Configure the egress rule of port 1/0/2 in VLAN 100 and VLAN 200 as Tagged,
and in VLAN 1050 as Untagged; Configure the egress rule of port 1/0/1 in VLAN 1050
as Tagged.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
