TP-Link T2600G Series User Manual

Configuring OAM Viewing OAM Statistics
User Guide
1001
Critical Events Displays the number of Critical Event link events that have occurred on the local link
or remote link.
Additionally, you can view the detailed information of the event logs in the Event Log Table
section.
Type Displays the types of the link event.
Location Displays the location where the link event occurred.
Timestamp Displays the time reference when the link event occurred.
Value Displays the number of symbol errors or frame errors in the period.
Window Displays the period of the link event.
Threshold Displays the threshold of the errors.
Accumulated
Errors
Displays the number of errors that have been detected since the OAM feature was
last reset.
3.2 Using the CLI
3.2.1 Viewing OAMPDUs
On privileged EXEC mode or any other configuration mode, you can use the following
command to view the number of OAMPDUs received and sent on the specified port.
show ethernet-oam statistics [ interface fastEthernet { port | port-list } | interface gigabitEthernet { port
|
port-list } | ten-gigabitEthernet { port | port-list }]
View the number of different OAMPDUs transmitted and received on the specified port, including
Information OAMPDU, Unique Event Notification OAMPDU, Duplicate Event Notification OAMPDU,
Loopback Control OAMPDU, Variable Request OAMPDU, Variable Response OAMPDU, Organization
Specific OAMPDUs, Unsupported OAMPDU, and Frames Lost Due To OAM (frames that are not transmitted
successfully on the OAM sublayer but not due to an internal OAM error).
The following example shows how to view the transmitted and received OAMDPUs on port
1/0/1.
Switch#show ethernet-oam statistics interface gigabitEthernet 1/0/1
Gi1/0/1
---------------------------------------------
Information OAMPDU TX : 28
Information OAMPDU RX : 28
Unique Event Notification OAMPDU TX : 0

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
