TP-Link T2600G Series User Manual

User Guide 280
Configuring Private VLAN Private VLAN Configurations
Step 4 switchport private-vlan mapping primary-vlan-id secondary-vlan-id
Add the specified port(s) to the private VLAN.
primary-vlan-id : Specify the ID of the primary VLAN. The ID ranges from 2 to 4094.
secondary-vlan-id : Specify the ID of the secondary VLAN. The ID ranges from 2 to 4094.
Step 5 show vlan private-vlan
Verify configurations of private VLAN.
Step 6 show vlan private-vlan interface [fastEthernet
port | gigabitEthernet port | ten-
gigabitEthernet
port | port-channel lag-id ]
Verify private VLAN configurations of ports.
port : Specify the ID of the port to show information.
lag-id : Specify the ID of the LAG to show information.
Step 7 end
Return to Privileged EXEC Mode.
Step 8 copy running-config startup-config
Save the settings in the configuration file.
Note:
When configuring the up-link port, you only need to add the port to one private VLAN and set the
port type as Promiscuous. The switch will automatically add the port to private VLANs with the
same primary VLAN.
The following example shows how to configure the port type of port 1/0/2 as Promiscuous,
and add it to the private VLAN composed of primary VLAN 6 and secondary VLAN 5.
Switch#configure
Switch(config)#interface gigabitEthernet 1/0/2
Switch(config-if)#switchport private-vlan promiscuous
Swtich(config-if)#switchport private-vlan mapping 6 5
Switch(config-if)#exit
Switch(config)#show vlan private-vlan
Primary Secondary Type Ports
--------- ------------- --------------- --------------
6 5 Community Gi1/0/2
Switch(config)#show vlan private-vlan interface gigabitEthernet 1/0/2
Port type
--------- ----------

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
