TP-Link T2600G Series User Manual

User Guide 232
Configuring VLAN-VPN Flexible VLAN-VPN Configuration
Step 4 switchport dot1q-tunnel mapping c-vlan sp-vlan [ descript ]
Set VLAN mapping entries for the specified port.
c vlan : Enter VLAN ID of the customer network.
sp vlan: Enter VLAN ID of the ISP network.
descript: Give a description to identify the VLAN Mapping.
Step 5 end
Return to privileged EXEC mode.
Step 6 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to enable VLAN mapping and set a VLAN mapping entry
named mapping1 on port 1/0/3 to map customer network VLAN 15 to ISP network VLAN
1040:
Switch#configure
Switch(config)#dot1q-tunnel mapping
Switch(config)#show dot1q-tunnel
VLAN-VPN Mode: Enabled
Mapping Mode: Enabled
Switch(config)#interface gigabitEthernet 1/0/3
Switch(config-if)#switchport dot1q-tunnel mapping 15 1040 mapping1
Switch(config-if)#show dot1q-tunnel mapping
Port C-VLAN SP-VLAN Name
----------- ---------- ------------ -----------
Gi1/0/3 15 1040 mapping1
Switch(config-if)#end
Switch#copy running-config startup-config

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
