User Guide 988
Configuring OAM Ethernet OAM Configurations
Step 3 ethernet-oam link-monitor symbol-period [ threshold threshold ] [ window window ]
[notify {disable | enable}]
Configure the relevant parameters of Error Symbol Period event.
threshold : Specify the threshold of received symbol errors within a specic period of time.
Valid values are from 1 to 4294967295, and the default value is 1.
window : Specify the time period in units of 100ms (for example, 2 refers to 200ms), in which
if the received errors exceed the threshold, a link event will be generated. Valid values are
from 10*100 to 600*100 ms, and the default value is 10*100 ms.
disable | enable:
Enable or disable notifications to report the link event. By default, it is
enabled.
Step 4 show ethernet-oam configuration [ interface fastEthernet {
port | port-list } | interface
gigabitEthernet {
port | port-list } | interface ten-gigabitEthernet { port | port-list }]
Verify the OAM configuration.
Step 5 end
Return to privileged EXEC mode.
Step 6 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to enable Error Frame event notification and configure
the threshold as 1 and the window as 1000 ms (10*100 ms) on port 1/0/1:
Switch#configure
Switch(config)#interface gigabitEthernet 1/0/1
Switch(config-if)#ethernet-oam link-monitor symbol-period threshold 1 window 10
notify enable
Switch(config-if)#show ethernet-oam configuration interface gigabitEthernet 1/0/1
Gi1/0/1
-----------------------------------------------------------
...
Symbol Period Error
Notify State : Enabled
Window : 1000 milliseconds
Threshold : 1 Error Symbol
...
Switch(config-if)#end
Switch#copy running-config startup-config
