User Guide 996
Configuring OAM Ethernet OAM Configurations
PeeringRemotelyRejected: The remote OAM entity rejects the local device.
NonOperHalfDuplex: Ethernet OAM is enabled but the port is in half-duplex operation. You should configure
the port as a full-duplex port.
Operational: OAM connection is established with the peer and OAM works normally.
Loopback Status: Displays the loopback status, including:
No Loopback: Neither the local client nor the remote client is in the loopback mode.
Local Loopback: The local client is in the loopback mode.
Remote Loopback: The remote client is in the loopback mode.
The displayed OAM information of the remote entity is as follows:
Mode: Displays OAM mode of the local entity.
MAC Address: Displays the MAC address of the remote entity.
Vendor (OUI): Displays the Vendor’s OUI of the remote entity.
Max OAMPDU: Displays the maximum size of OAMPDU.
Remote Loopback: Displays whether the remote entity supports Remote Loopback.
Unidirection: Displays whether the remote entity supports Unidireciton.
Link Monitoring: Displays whether the remote entity supports Link Monitoring.
Variable Request: Displays whether the remote entity supports Variable Request.
PDU Revision: Displays the PDU Revision of the remote entity.
Vendor Information: Displays the vendor information of the remote entity.
The following example shows how to view the OAM status of port 1/0/1:
Switch(config)#show ethernet-oam status interface gigabitEthernet 1/0/1
Gi1/0/1
Local Client
-----------------------------------------------------------
OAM : Enabled
Mode : Active
Max OAMPDU : 1518 Bytes
Remote Loopback : Supported
Unidirection : Not Supported
