TP-Link T2600G Series User Manual

User Guide 112
Configuring LAG LAG Configuration
Note:
Clearing all member ports will delete the LAG.
■ Configuring LACP
Choose the menu L2 FEATURES > Switching > LAG > LACP to load the following page.
Figure 2-4 LACP Config
Follow these steps to configure LACP:
1) Specify the system priority for the switch and click Apply.
System Priority Specify the system priority for the switch. A smaller value means a higher priority.
To keep active ports consistent at both ends, you can set the system priority
of one device to be higher than that of the other device. The device with higher
priority will determine its active ports, and the other device can select its active
ports according to the selection result of the device with higher priority. If the two
ends have the same system priority value, the device with a smaller MAC address
has the higher priority.
2) Select member ports for the LAG and configure the related parameters. Click Apply.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
