Configuring Private VLAN Overview
User Guide
275
If private VLAN is configured on Switch B, Switch A only needs to recognize primary VLAN,
VLAN5; and end users can be isolated by secondary VLANs, VLAN2, VLAN3 and VLAN4,
saving VLAN resources for Switch A.
Figure 1-2 Topology of Private VLAN
Switch A
Switch B
VLAN5
VLAN2 VLAN3 VLAN4
